DROPOUT AIR TREATMENT WATER SEPARATOR
Dropout offers a unique patent protected in-line protection solution for your air supply where moisture free air at the point of use is required or essential.
Recommended where there is a high concentration of water in the air supply.
Can also be used as an effective lower cost alternative to dryers.
- Guaranteed to remove 99.9999% liquid (water & oil)
- 99% Solid particulate removal
- Particulate removal to 1 Micron
- Low maintenance, no replacement filter elements required
How do they work?
- Dirty air enters the inlet port and is directed through our primary chamber where directional changes cause the air to spin, removing the heaviest content.
- The air then passes through a small annulus causing the air to expand and rapidly cool.
- The air then passes through the DCC (Dropout clarification chambers) where precision engineered venturis deflect the air causing particle coalescence.
- Liquid then falls to the base of the unit where it is collected and drained.
- Multiple DCCs polish the air of all remaining aerosol particles leaving the downstream air of the Dropout clean and dry.
Nylon & Aluminium Range
| Part No | Material description | Port size | Outlet Drain | CFM | LPM |
|---|---|---|---|---|---|
| DO300PA | Nylon | 1/2" | Auto | 11 | 300 |
| DO300A | Aluminium | 1/2" | Manual | 11 | 300 |
| DO600A | Aluminium | 3/4" | Manual | 21 | 600 |
| DO900A | Aluminium | 3/4" | Manual | 32 | 900 |
| DO2000A | Aluminium | 1" | Manual | 71 | 2000 |
| DO4000A | Aluminium | 1" | Manual | 141 | 4000 |
| DO300A/AD | Aluminium | 1/2" | Auto | 11 | 300 |
| DO600A/AD | Aluminium | 3/4" | Auto | 21 | 600 |
| DO900A/AD | Aluminium | 3/4" | Auto | 32 | 900 |
| DO2000A/AD | Aluminium | 1" | Auto | 71 | 2000 |
| DO4000A/AD | Aluminium | 1" | Auto | 141 | 4000 |
| Part No | Material description | Port size | Outlet Drain | CFM | LPM |
|---|---|---|---|---|---|
| DO60S | 304 Stainless steel | 1/4" | Manual | 2 | 60 |
| DO150S | 304 Stainless steel | 1/4" | Manual | 4 | 100 |
| DO300S | 304 Stainless steel | 1/2" | Manual | 11 | 300 |
| DO600S | 304 Stainless steel | 3/4" | Manual | 21 | 600 |
| DO900S | 304 Stainless steel | 3/4" | Manual | 32 | 900 |
| DO1500S | 304 Stainless steel | 1" | Manual | 64 | 1800 |
| DO2000S | 304 Stainless steel | 1" | Manual | 71 | 2000 |
| DO4000S | 304 Stainless steel | 1" | Manual | 21 | 4000 |
Stainless Steel Range
Auto Drain Attachments
| Part No | Material | Port size |
|---|---|---|
| DOAD128 | Aluminium | 1/2" |
| DOAD228BSPT304 | 304 Stainless | 1/2" |
